Floe V-2602 - Page 24

NO.
PART NO.
QTY.
DESCRIPTION
NO.
PART NO.
QTY.
DESCRIPTION
1
002-00049-01
4
POST, CORNER .090" WALL - 74"
50
001-74402-00
8
CARRIAGE BOLT, 5/16-18 x 3 1/2" SS 18-8
2
002-00053-00
2
BEAM, LIFT FRAME .09 - 48"
51
001-71024-00
16
FLAT WASHER, 5/8" x 1.25" x .060 SS
3
002-04314-00
4
BRACKET, LEVEL LEG - 2.563"
52
001-26969-00
4
PIN, GROOVE 5/32" x 15/16"
4
002-00187-00
2
BEAM, LIFT FRAME 121" (.090)
53
001-26911-00
4
PIN, DOWEL 3/16" x 7/8"
5
002-04015-00
7
CLAMP, CRADLE - 1.5"
54
007-05023-00
4
BEVEL GEAR, TOP - 1:1
6
002-04017-00
1
CLAMP, CRADLE LIFT - 2.5"
55
007-05024-00
4
BEVEL GEAR, BOTTOM - 1:1
7
002-04022-01
2
V-BRACE, 76.938" x .125"
56
007-05079-01
4
SCREW, BEVEL GEAR ADJUSTMENT
8
002-00004-01
1
CLAMP, OUTER FRAME SHEAVE - 5"
57
001-70209-00
8
HHCS, 1/2-13 x 1 1/2" SS 18-8
9
002-00005-01
4
CLAMP, FRAME INNER - 5" EXT. VERSION
58
006-15200-00
3
CAP, VINYL 3" SQ. LIFT CORNER
10
002-00003-01
3
CLAMP, LOWER FRAME OUTER - 5"
59
001-76069-00
8
FLAT WASHER, 5/8 (LIFT) NYLON
11
002-04031-00
4
GUIDE, CRADLE (EXT.) -4.25"
60
006-15022-00
1
CAP, VINYL-CANOPY/WINCH INSERT
12
002-00001-00
2
BRACKET, UPPER LFTG./V-BRACE
61
001-70215-00
6
HHCS, 1/2-13 x 3" SS 18-8
13
001-70117-00
4
HHCS, 3/8-16 X 3 1/2" SS 18-8
14
002-00002-00
2
BRACKET, UPPER V-BRACE - 4"
15
002-03201-00
2
CRADLE, SIDE - 61"
16
002-00204-00
1
BEAM, END CRADLE 126.375" (.110)
17
002-03203-00
2
CLAMP, V-BRACE (FEMALE)
18
002-03204-00
2
CLAMP, V-BRACE (MALE)
62
111-00058-00
ASS'Y, SIDE CRADLE BEAM (A)
19
111-00216-01
4
WELD'T, INNER LEG 2000-5000#
INCLUDES ITMES 11,15,24,25,26,30,39,46,47
20
911-20601-00
4
U-CLAMP, CRADLE 2.125"
21
911-14201-00
1
CANOPY/WINCH INSERT, 38"
63
111-00059-00
ASS'Y, SIDE CRADLE BEAM (B)
22
911-15508-00
1
BEAM, F/R CRADLE - .110 - 126.375"
INCLUDES ITEMS 11,15,24,25,26,30,39,46,47
23
111-00000-00
4
SAND PAD WELDMENT
24
006-10202-00
4
PAD, WEAR - 1/2 x 7/8" x 2"
64
111-00469-00
ASS'Y, END CRADLE 126.375" (.110")
25
006-11001-00
4
UHMW , 1/4" x 1/2" x 5"
INCLUDES ITEMS 16,27,30,39,45
26
007-07700-00
4
SPACER, 1.297" (SIDE CRADLE)
27
007-07701-00
2
SPACER, 1.055" (.090" FRONT)
65
111-00394-02
ASS'Y, CORNER POST "A" - .09 - 74"
28
007-09001-00
2
CABLE, SIDE LEVELING 118.875"
INCLUDES ITEMS 1,19,21,50,51,58,68,69,70
29
007-09511-00
1
CABLE, FRONT LEVELING 205.688"
30
111-00107-00
6
ASS'Y, SHEAVE 5" - 5/16" CABLE
66
111-00395-02
ASS'Y, CORNER POST "B" - .09 - 74"
31
001-70115-00
4
HHCS, 3/8-16 X 3" SS 18-8
INCLUDES ITEMS 1,19,50,51,68,769
32
001-70218-00
4
HHCS, 1/2-13 X 3 3/4" SS 18-8
33
001-70210-00
8
HHCS, 1/2-13 x 1 3/4" SS 18-8
67
111-00396-02
ASS'Y, CORNER POST "C" - .09 - 74"
34
007-06201-00
1
SHEAVE, 3" FRONT CABLE 1/2" ID
INCLUDES ITEMS 1,19,50,51,58,68,69
35
001-70207-00
1
HHCS, 1/2-13" x 1 1/4 " SS 18-8
36
001-70211-00
5
HHCS, 1/2-13 x2" SS 18-8
68
111-00397-02
ASS'Y, CORNER POST "D" - .09 - 74"
37
001-70217-00
14
HHCS, 1/2-13" x 3 1/2" SS 18-8
INCLUDES ITEMS 1,19,50,51,58,68,69
38
001-70221-00
2
HHCS, 1/2-13 x 4 1/2" SS 18-8
39
001-70816-00
6
NUT, JAM 5/8-11 SS 18-8
69
111-00234-01
ASS'Y, INNER LEG 2000-5000#
40
002-04140-00
1
HOLDER, CABLE
INCLUDES ITEMS 3,19,58,59,52,53,54,55,56,57,59
41
001-71022-00
37
FLAT WASHER, 1/2" USS SS 18-8
42
001-76071-00
8
NUT,3/8-16 ALUM. NYLOCK
70
111-00411-01
ASS'Y, CANOPY/WINCH INSERT
43
001-76072-00
42
NUT, 1/2-13 x 4 1/2" SS 18-8
21,35,38,43,60
44
001-71023-00
16
FLAT WASHER, .51ID x .75 OD SS
45
001-70310-00
2
HHCS, 5/8-11 x 1 3/4" SS 18-8
46
001-70313-00
4
HHCS, 5/8-11 x 2 1/2" SS 18-8
47
006-10206-00
8
SPACER, SIDE CRADLE SHEAVE
48
001-71021-00
12
FLAT WASHER, 1/2" 18-8 SS
49
001-70861-00
8
NUT,5/16-18 ALUMINUM NYLOCK
SUB-ASSEMBLIES
V-2602 LIFT
LIFT P/N 511-26080-00
