Floe V-3600 - Page 17

Contents for Step 4
(
1
)
1/2
x
1 3/4” ss Bolt
Torque to
50
ft. lbs.
(8) 1/2” Alum. Nuts
(8) 1/2 x 1 1/2” ss Bolts Torque to 45 ft. lbs.
NOTE
(1) ½” Nut and (1) ½”
Bolt are used in Step
5-E to attach cradle
clamp to cradle beam
and cradle u-clamp.
