NO. PART NUMBER DESCRIPTION QTY NO. PART NUMBER DESCRIPTION QTY
93 111-00139-00 Ass'y, Front Cradle Beam -127" 1 106 111-00426-01 Ass'y, Corner Post "B" Motor 1
23 001-70365-00 HHCS, 3/4-10 x 3" ss 2 27 001-70861-00 Nut, Nylock 5/16-18 - Alum. 2
25 001-70817-00 Nut, 3/4-10 Jam ss 2 32 001-74404-00 CB, 5/16-18 x 5" ss 18-8 2
52 002-04215-00 Beam, End Cradle (127") 1 40 002-00077-01 Post, Corner Motor "B" 1
71 006-10208-00 Spacer, Front Cradle Sheave 4 58 002-04227-00 Clamp, Frame (LF RR) (Welded to Corner Post) 1
86 007-07705-00 Spacer, 1.938" Front Cradle 2 73 006-15500-00 Cap, Vinyl 4.500" Sq. x 1.5" 1
88 007-09110-00 Cable, Front Leveling 221.625" 1 104 111-00424-01 Ass'y, Inner Leg 6-8000 1
99 111-00200-00 Ass'y, 7 1/4" Sheave 2
NO. PART NUMBER DESCRIPTION QTY
NO. PART NUMBER DESCRIPTION QTY 107 111-00427-01 Ass'y, Corner Post "C" 1
95 111-00188-02 Ass'y, Side Cradle Right 1 27 001-70861-00 Nut, Nylock 5/16-18 - Alum. 2
22 001-70363-00 HHCS, 3/4-10 x 2 1/2" ss 2 32 001-74404-00 CB, 5/16-18 x 5" ss 18-8 2
25 001-70817-00 Nut, 3/4-10 Jam ss 2 41 002-00078-01 Post, Corner "C & D" 1
66 002-04357-00 Beam, Side Cradle (B) 6-8000# 1 48 002-04209-00 Clamp, Frame (RF LR) (Welded to Corner Post) 1
70 006-10207-00 Spacer, Side Cradle Sheave 4 73 006-15500-00 Cap, Vinyl 4.500" Sq. x 1.5" 1
72 006-11002-00 UHMW, 1/2" x 6.5" x .25" 2 104 111-00424-01 Ass'y, Inner Leg 6-8000 1
85 007-07704-00 Spacer, 1.297 Side Cradle 2
88 007-09105-00 Cable, Side Leveling - 190.5" 1 NO. PART NUMBER DESCRIPTION QTY
98 111-00199-00 Ass'y, 6" Side Level Sheave 2 108 111-00428-01 Ass'y, Corner Post "D" 1
101 111-00251-00 Ass'y, Cradle Guide 2 27 001-70861-00 Nut, Nylock 5/16-18 - Alum. 2
32 001-74404-00 CB, 5/16-18 x 5" ss 18-8 2
NO. PART NUMBER DESCRIPTION QTY 41 002-00078-01 Post, Corner "C & D" 1
96 111-00189-02 Ass'y, Side Cradle Left 1 58 002-04227-00 Clamp, Frame (LF RR) (Welded to Corner Post) 1
22 001-70363-00 HHCS, 3/4-10 x 2 1/2" ss 2 73 006-15500-00 Cap, Vinyl 4.500" Sq. x 1.5" 1
25 001-70817-00 Nut, 3/4-10 Jam ss 2 104 111-00424-01 Ass'y, Inner Leg 6-8000 1
65 002-04356-00 Beam, Side Cradle (A) 6-8000# 1
70 006-10207-00 Spacer, Side Cradle Sheave 4 NO. PART NUMBER DESCRIPTION QTY
72 006-11002-00 UHMW, 1/2" x 6.5" x .25" 2 110 111-00430-01 Ass'y, Ball Screw Tube 6-8000# 1
85 007-07704-00 Spacer, 1.297 Side Cradle 2 1 001-16369-00 HHCS, 3/4-16 x 4" Grade 5 Plain 1
88 007-09105-00 Cable, Side Leveling - 190.5" 1 2 001-23877-00 SHCS, 1/2-20 x 1 1/2" (Black) 2
98 111-00199-00 Ass'y, 6" Side Level Sheave 2 5 001-33092-00 Flat Washer, SAE 3/4" Zinc 1
101 111-00251-00 Ass'y, Cradle Guide 2 11 001-70123-00 HHCS, 3/8-16 x 5" 18-8 ss 1
14 001-70203-00 HHCS, 1/2-13 x 3/4" 18-8 ss 2
NO. PART NUMBER DESCRIPTION QTY 18 001-70215-00 HHCS, 1/2-13 x 3" 18-8 ss 2
104 111-00424-01 Ass'y, Inner Leg 6-8000 1 29 001-71021-00 Flat Washer, 1/2" 18-8 SS 2
3 001-26911-00 Pin, Dowel 3/16" x 7/8" 1 33 001-74423-00 CB 1/4-20 x 2" ss 18-8 1
4 001-26969-00 Pin, Groove 5/32"x 1.125" Zinc 1 34 001-75001-00 Nylock, 1/4-20 Alum. 1
29 001-71021-00 Flat Washer, 1/2" 18-8 SS 2 36 001-76071-00 Nut, Nylock 3/8-16 Alum. 1
31 001-71024-00 Flat Washer, 5/8"x1.25"x.060 SS 4 37 001-76072-00 Nut, Nylock 1/2-13 Alum. 2
35 001-76069-00 Flat Washer, 5/8 (Lift) Nylon 2 38 001-93530-00 Nut, Slotted M30 x 1.5 1
61 002-04245-00 Bracket, Level Leg - 4" 1 68 006-10021-00 Sleeve, UHMW Ball Screw Support 1
76 007-05023-00 Bevel Gear, Top 1:1 1 74 006-22202-00 Sleeve, Steel 1" x 2.25" Lg. 1
78 007-05079-01 Screw, Bevel Gear Adjustment 1 75 007-05013-00 Plate, End Stop (Ball Screw) 1
91 007-15024-00 Bevel Gear, Bottom (Fab) 1 79 007-05126-00 Fitting, Grease M8 X 1 (Flush) 2
103 111-00423-01 Weldment, Inner Leg 6-8000# 1 80 007-05222-00 Key, 1/4" SQ x 3" Long 1
81 007-05224-00 Coupler, Rigid 1" x 2" x 3" 1
NO. PART NUMBER DESCRIPTION QTY 90 007-09161-00 Cable, Lifting - 237.0" 6-8000# 1
105 111-00425-01 Ass'y, Corner Post "A" Lifting 1 92 011-15015-00 Ball Screw, 40-10 mm 1930.4 mm 1
26 001-70819-00 Nut, 1"-8 Jam ss 2 100 111-00249-00 Ass'y, Ball Nut Block 6-8000# 1
27 001-70861-00 Nut, Nylock 5/16-18 - Alum. 2 102 111-00311-00 Ass'y, Bearing Block w/ Bearing 1
32 001-74404-00 CB, 5/16-18 x 5" ss 18-8 2 109 111-00429-01 Weld't, Ball Screw Tube 6-8000# 1
39 002-00076-01 Post, Corner Lifting "A" 1 111 111-60800-00 Ass'y, Limit Switch 6000-8000 1
48 002-04209-00 Clamp, Frame (RF LR) (Welded to Corner Post) 1
56 002-04224-00 Clamp, Pulley (Inner) 1
59 002-04230-00 Clamp, Pulley (Outer) 1
73 006-15500-00 Cap, Vinyl 4.500" Sq. x 1.5" 1
82 007-05500-00 Pin, Sheave - 1" x 6.688" 1
87 007-07708-00 Spacer, Pulley 6000-8000# 2
97 111-00198-00 Ass'y, 7" Lifting Sheave 2
104 111-00424-01 Ass'y, Inner Leg 6-8000 1
VSD 6500/8000 FRAME BILL OF MATERIALS – SUB-ASSEMBLIES
LIFT P/N 511-80075-01
