O
PTIONAL
E
QUIPMENT
Flory Industries offers some optional equipment configurations for 33 Series Sweeper for use in
specialized environments. Listed below are some of the options; please contact the Factory or your Flory
Authorized Representative for more information.
Berm Brush Option
The brushes on the outer ends of the sweeping heads can be adjusted manually for the width of coverage.
Manual adjustments also are required for setting the depth and rotating the brush “head” to meet different field
conditions such as flat ground or borders. The speed of the individual brushes can be changed by means of a flow
control valve located on the back side of each sweeping head. For best performance, the flow control valves for
these brushes should be set for approximately 100 RPM.
This brush takes a lot of abuse and may need to be replaced more than once during a normal sweeping
season.
Side Kick Option
When folding and unfolding the side kick, proper sequence must be adhered to. To fold the side kick up
into the transport position, first retract the fold (top) cylinder about 75% of the way. Then extend the lift (bottom)
cylinder all the way out. When the lift cylinder is fully extended, retract the fold cylinder the rest of the way until it
is fully retracted. When unfolding the side kick take extra caution, the improper sequence of events could
lead to damage of the side kick. Start by extending the fold cylinder about 25% of the way. Next, retract the lift
cylinder until there is about 1” of stroke left showing. Then finish extending the fold cylinder the rest of the way
and the side kick depth wheels are touching the ground. Finally turn the reel switch to the ‘ON’ position, when the
reel position is ‘ON’ the lift cylinder will go into ‘FLOAT’ mode and no longer supporting the
structure.
If the reel is turned ‘ON’ while the side kick is elevated, the side kick will come
crashing down to the ground. Causing damage to the machine and possible injury.
108
