Flott Turbo Drill - Page 22

212516 D/GB
21
GB
Order no.
figure item designation Turbo Drill TB 10 Plus TB 13 Plus SB 13 Plus
5 1 Motor * 212561 212561 212561 212561
5 2 V-ripped belt *
DIN 7867-6PJx483 mm
--- --- 010046 010046
5 2 V-ripped belt *
DIN 7867 5PJx406 mm
--- 009687 --- ---
5 2 V-ripped belt *
DIN 7867-3PJx350 mm
010073 --- --- ---
5 3 Motor holder 212662 212662 212662 212662
5 4 Guide rod 212512 212512 212512 212512
5 5 Frequency converter * 212571 212571 212571 212571
5 6 Clamping lever M10
Distance piece
212517
217909
212517
217309
---
---
---
---
5 7 Pneumatic spring 007820 007820 --- ---
5 8 C-frame 212556 212556 --- ---
6 1 LED ligth 010047 010047 010047 010047
6 2 Mounting angle 212586 212586 212586 212586
6 3 Micro limit switch * 008537 008537 008537 008537
6 4 Position sensor 212582 212582 212582 212583
6 5 Mounting plate 212583 212583 212583 212582
* consumable parts
