11
The bees remain undisturbed on the surface of the
comb. If there does happen to be a bee down an
empty cell it wont get injured as there is enough
space between the comb walls.
INSIDE THE HONEYCOMB THE CELLS HAVE NOW SPLIT AND
TURNED INTO CHANNELS FOR THE HONEY TO FLOW DOWN.
HONEY
TROUGH
CAP
HONEY TUBE
FLOW
KEY
KEY
ACCESS
CAP
*Frame remains in
the hive for harvest, shown
separately for illustrative
purposes only
1 Remove the key access cap and honey trough cap
2 Insert honey tube into hole
3 Insert Flow Key into
LOWER slot
4 Rotate key 90 degrees downwards to split the
honeycomb cells
To Next Page
