16 Instruction Manual
Cal Mode (hidden menu)
Cal mode is a hidden menu, for the setup of the current output and calibration. To access this
menu the correct password must be entered, Step through the main Menu until Menu 2 is
displayed, then press and hold M until Cal Mode? appears on the screen.
Cal Mode
M-cont S-enter
Press S to enter
M3_1 set 4mA
750
Connect an accurate milliamp meter to the current output terminals
Select a value that drives the output to 4mA (approx. 750)
Press ► repeatedly until cursor is under digit to be edited
Press ▲ repeatedly until desired value is displayed and M to continue
M3_2 set 20mA
3800
Connect an accurate milliamp meter to the current output terminals
Select a value that drives the output to 20mA (approx. 3800)
Press ► repeatedly until cursor is under digit to be edited
Press ▲ repeatedly until desired value is displayed and M to continue
NOTE:
Changes that are made to values in the menu system will only be saved when accessing the
Save & exit menu and the S button is pressed.
