NORDSTROM HYPREGUN-PLUS 5Q
Flow Control
Nordstrom Valves
Flow Control
Nordstrom Valves
Parts List
Figure 1
Ref. Part Name Part Number Qty. Reqd.
1 Air motor 1900037 1
3 Throttle valve 927325 1
5 Nylon air tube 60023 1
6 Straight male connector 1927418 1
11 O-ring 934014 6
12 Yoke 40866 1
13 Hex head capscrew 910007 2
15 Lock washer 932525 2
16 Yoke retaining screw 40867 2
18 Base 60001 1
19 Cylinder 40869 2
20 Cylinder head 40870 2
21 Cylinder gasket 40871 2
22 Piston rod 40872 2
23 Piston retaining screw 40873 2
24 O-ring 934008 2
25 Piston retaining washer 40874 2
26 Piston packing 40875 2
27 Retaining ring 927338 4
28 O-ring 934309 2
29 O-ring 934015 2
34 Follower 40880 1
35 O-ring 934068 1
36 Down tube assembly 60018 1
54 Coupling 1900312 1
60 Yoke retaining washer 40890 2
62 Piston retaining washer for O-ring 41121 2
63 Valve screw 1900051 1
65 Pressure gauge 1900052 1
70 Nameplate 1900200 1
72 Can shield 60003 1
75 Axle 1900018 2
79 Wheel 60012 2
81 3/8" – 16 x 1/2" setscrew 1900034 2
91 Metal air tube assembly 1900132 1
93 90° male connector 927417 1
99 Hex bushing 904273 1
Detail 1
Ref. Part Name Part Number Qty. Reqd.
31 Hex capscrew 910334 2
32 Washer 900836 4
61 Spacer 1939100 2
88 Pipe plug 2761011 2
90 Lock nut 1939115 2
Section A-A
Ref. Part Name Part Number Qty. Reqd.
4 Relief valve 1900008 1
6 Straight male connector 1927418 1
7 Nipple 927310 1
8 Ram needle valve 1900039 1
9 O-ring 934003 1
10 Gasket - fiber 927330 1
17 Air coupler 927308 1
Figure 2
Ref. Part Name Part Number Qty. Reqd.
30 Restrictor ell assembly 40876 1
57 Nipple 927309 1
71 Handle 1900068 1
74 Kick stand 60005 2
76 Spring 60008 1
77 Retaining ring 904672 2
82 3/8" steel washer 932602 1
83 3/8" medium steel lock washer 932527 2
84 3/8" x 2" steel hex head capscrew 902278 1
85 3/8" – 16 steel nut 900085 1
86 Hex nut 920402 1
87 5/16" – 18 x 1-1/4" steel hex head
capscrew
909208 1
Section B-B
Ref. Part Name Part Number Qty. Reqd.
14 Socket head capscrew 939005 4
33 Pump body w/packing 1900019 1
57 Nipple 927309 1
59 Gasket 1900050 1
64 Relief valve 927348 1
66 Hose, 10 foot 1900053 1
67 Swivel - L type 927343 1
68 Swivel - straight type 927437 1
69 Button head coupler 64584 1
78 Shutoff & relief valve 60010 1
89 Piston packing 1900064 1
Section C-C
Ref. Part Name Part Number Qty. Reqd.
37 Air motor piston rod 1900300 1
38 Roll pin 1900301 2
39 Spring 1900047 1
40 Steel ball 1900040 1
41 Tube extension 1900302 1
42 Piston & cylinder 1900303 1
43 Gasket 1900049 2
44 Extension 1900304 1
45 Primer rod & foot valve assembly 1900305 1
46 Foot valve stop washer 40886 1
47 Gasket 1900307 1
48 Valve seat 1900306 1
49 Steel washer, special 1900308 1
50 Primer body 1900310 1
51 Hex nut 1900041 1
52 Cotter pin 931000 1
53 Roll pin 1900311 1
54 Coupling 1900312 1
55 Roll pin 1900313 1
