Replacement Parts and Kits
Kick Stand Kit #1900162
(single kick stand only)
Part Part *
Qty. Number Description
1 60005 Kick stand (74)
1 60008 Spring (76)
1 900085 Nut (85)
1 902278 Capscrew (84)
1 909208 Capscrew (87)
1 932527 Lock washer (83)
1 932602 Washer (82)
1 920402 Nut (86)
Hypregun-Plus 5Q
Hoses by Length
(1/2" – 27 Female each end)
Hose Part Hose Part
Length Number Length Number
6 ft. 47504 25 ft. 47506
10 ft. 1900053 30 ft. 47507
12 ft. 1900032 50 ft. 47508
15 ft. 47535 75 ft. 1900022
20 ft. 47505
Major Repair Kit #1900061
Part Part
Qty. Number Description
1 47524 Button head coupler repair kit
1 1900016 Down tube kit
Button Head Coupler
Repair Kit #47524
(1)
Part Part
Qty. Number Description
1 64585 Spring
1 64586 Washer
1 934008 O-ring
1 64582 Valve
Wheel Kit #1900080
(single wheel only)
Part Part *
Qty. Number Description
1 60012 Wheel (79)
1 904672 Retainer ring (77)
1 1900018 Axle (75)
1 1900034 Setscrew (81)
Air Supply Assembly #1900120
Part Part *
Qty. Number Description
1 60023 Nylon air tube (5)
1 927417 90° male connector (93)
1 1927418 Straight male connector (6)
Connectors are complete with nut and ferrule.
Minor Repair Kit #1900059
(1)
Part Part *
Qty. Number Description
2 40871 Gasket (21)
2 40875 Packing (26)
1 927330 Gasket, fiber (10)
4 927338 Retaining ring (27)
1 934003 O-ring (9)
2 934008 O-ring (24)
6 934014 O-ring (11)
2 934015 O-ring (29)
1 934068 O-ring (35)
2 934309 O-ring (28)
1 1900039 Ram needle valve (8)
1 1900051 Valve screw (63)
Down Tube Kit #1900016
(1)
Part Part *
Qty. Number Description
1 40886 Foot valve stop washer (46)
1 931000 Cotter pin (52)
1 1900040 Steel ball (40)
1 1900041 Hex nut (51)
1 1900047 Spring (39)
2 1900049 Gasket (43)
1 1900050 Gasket (59)
1 1900064 Piston packing (89)
2 1900301 Roll pin (38)
1 1900303 Piston & cylinder (42)
1 1900305 Primer rod & foot valve assy. (45)
1 1900306 Valve seat (48)
1 1900307 Gasket (47)
1 1900308 Steel washer (49)
* Numbers in parentheses denote illustration number
(1)
Component of Major Repair Kit 1900061
