Replacement Parts and Kits
Illustration Part Part
Number Number Description
(Figure 2, page 6)
30 40876 Restrictor ell assembly
57 927309 Nipple
71 1900068 Handle
74 60005 Kick stand
(5)
76 60008 Spring
(5)
77 904672 Retaining ring
(4)
82 932602 Washer
(5)
83 932527 Lock washer
(5)
84 902278 Capscrew
(5)
85 900085 Nut
(5)
86 920402 Nut
(5)
87 909208 Capscrew
(5)
(Section B-B, page 6)
14 939005 Socket head capscrew
33 1900019 Pump body with packing
57 927309 Nipple
59 1900050 Gasket
(3)
64 927348 Relief valve
66 1900053 Hose - 10 foot
67 927343 Swivel - L type
68 927437 Swivel - straight type
69 64584 Button head coupler
78 60010 Shut off and relief valve
89 1900064 Piston packing
(3)
(Section C-C, page 6)
37 1900300 Air motor piston rod
38 1900301 Roll pin
(3)
39 1900047 Spring
(3)
40 1900040 Steel ball
(3)
41 1900302 Tube extension
42 1900303 Piston & cylinder
(3)
43 1900049 Gasket
(3)
44 1900304 Extension
45 1900305 Primer rod & foot valve
assembly
(3)
46 40886 Foot valve stop washer
(3)
47 1900307 Gasket
(3)
48 1900306 Valve seat
(3)
49 1900308 Steel washer
(3)
50 1900310 Primer body
51 1900041 Hex nut
(3)
52 931000 Cotter pin
(3)
53 1900311 Roll pin
(3)
54 1900312 Coupling
(3)
55 1900313 Roll pin
(Detail-1, page 5)
31 910334 Hex capscrew
32 900836 Washer
61 1939100 Spacer
88 2761011 Pipe plug
90 1939115 Lock nut
Miscellaneous Repair Parts
Illustration Part Part
Number Number Description
Figure 1, Page 5
1 1900037 Air motor
47510 Air motor repair kit
3 927325 Throttle valve
5 60023 Nylon air tube
(7)
6 1927418 Straight male connector
11 934014 O-ring
(2)
12 40866 Yoke
13 910007 Hex head capscrew
15 932525 Lock washer
16 40867 Yoke retaining screw
18 60001 Base
19 40869 Cylinder
20 40870 Cylinder head
21 40871 Cylinder gasket
(2)
22 40872 Piston rod
23 40873 Piston retaining screw
24 934008 O-ring
(2)
25 40874 Piston retaining washer
26 40875 Piston packing
(2)
27 927338 Retaining ring
(2)
28 934309 O-ring
(2)
29 934015 O-ring
(2)
34 40880 Follower
35 934068 O-ring
(2)
36 60018 Down tube assembly
54 1900312 Coupling
60 40890 Yoke retaining washer
62 41121 Piston retaining washer for O-ring
63 1900051 Valve screw
(2)
65 1900052 Pressure gauge - 15,000 psi
70 1900200 Nameplate
(6)
72 60003 Can shield
75 1900018 Axle
(4)
79 60012 Wheel
(4)
81 1900034 Setscrew
(4)
91 1900132 Metal air tube assembly
(8)
93 927417 90° male connector
99 904273 Hex bushing
Section A-A, page 6
4 1900008 Relief valve
6 1927418 Straight male connector
7 927310 Nipple
8 1900039 Ram needle valve
(2)
9 934003 O-ring
(2)
10 927330 Gasket, fiber
(2)
17 927308 Air coupler
(2)
Component of minor repair kit 1900059
(3)
Component of down tube kit 1900016
(4)
Component of wheel kit 1900080
(5)
Component of kick stand kit 1900162
(6)
Not available as repair part
(7)
Nylon air tube not available with nuts and ferrules - see air
supply assembly 1900120 on page 8
(8)
Complete with nuts and ferrules
