NT 3000 Series Electro-Pneumatic Transducer Module FCD VLENIM0047-05 - 01/10
8
Figure 5 – XL Positioner with NT 3000 Transducer
Zero Arm
Range Arm
Range
Adjustment
Locking
Screw
Range
Adjustment
Gear
Cam
Vent Screen
Feedback
Spring
Instrument
Signal
Capsule
Mounting
Screws
Terminal Block
Current Loop
Termination (-)
Current Loop
Termination (+)
Grounding
Screw
Span
Adjustment
Zero
Adjustment
Zero Adjustment
Locking Knob
Zero Adjustment Knob
