Flowserve Valtek GS User Manual

Valtek GS General Service Valve FCD VLENIM0300-00-A4 08/14
22
1
108
55
20
58
8
50
80
109
87
88
93
7
110
48
42
59
106
59
6
114
40
Figure 16: Complete valve parts
17 Parts List
1)
see page 17,
2)
and
3)
see page 18
Item
Part Available Materials
Spare Parts
WW
1)
EU
2)
1 1.1 Body 1.0619 A216 WCC 1.4408 A351 CF8M
6 2.4 Bellows seal Unit 316 SS
7 3.15 Head 1.0460
or
1.0619
A105
or
A216 WCC
1.4404
or
1.4408
316 L
or
A351 CF8M
8 2.3 Lock Bushing 316 SS
20 2.1 Seat Ring 316 SS S
30 2.26 Multi. Cylinder
3)
1.4571 K
31 2.9 Cage
2)
A351 CF8M
40 3.1 Standard Bonnet
Extension Bonnet
Bellows Seal Bonnet
1.0460
or
1.0619
A105
or
A216 WCC
1.4404
or
1.4408
316 L
or
A351 CF8M
42 3.14 Plug Screw A2
48 3.13 Gasket Pure Graphite D
50 2.2 Contoured Plug
316 SS (Alloy 6) K
Quick Open
55 2.5 Profile Ring Pure Graphite S
56 2.10 Cage Gasket
2)
Pure Graphite
58 1.2 Bonnet Gasket
Pure Graphite on Support Plate from 1.4401
D59 2.15 Head Gasket Pure Graphite
60 2.8 Profile Ring
1)
Pure Graphite
65 2.12 Sealing Ring
2)
PTFE-Rings
66 2.21 Driving Band
2)
PTFE
80 3.4 Packing Follower 316 SS
83 3.1.1 Lower Stem Guide 316 SS (nitrided)
87 3.6 Upper Stem Guide 316 SS
88 3.3 Packing PTFE-Rings
D
Graphite-Rings
91 2.7 Seal Carrier
1)
316 SS
93 3.2 Packing box ring 316 SS
106 3.17 Stud Bolt KG A193 A2-70 A193
108 1.3 Stud Bolt KG A193 A2-70 A193
109 3.7 Belleville Spring 1.4310
110 3.16 Hex Nut KG A194 A2-70 A194
113 2.6 Hex Nut
1)
316 SS
114 1.4 Hex Nut KG A194 A2-70 A194
133 2.28 Spring
3)
1.4568
1)
WorldWide
2)
European Union K = Plug Kit, S = Seat Kit, D = Gasket Kit
