7
WATERFALL MOUNTS
Suggested application: Ideal for waterfall (wire) decking on pallet racks or
rolling tables. Hardware included: long or short “V” mounts.
For proper uniformity and flexibility for adjustments, position SPYDR with light
bars perpendicular to the length of the rack.
To mount your SPYDR using waterfall mounts, place SPYDR fixture gently
below the desired hanging area. Identify four points on the waterfall
decking that align with the light bars located second from the end.
NOTE: Hangers to be attached only to the light bars second from
the end.
Loop mounting hardware on the lower wire deck. Installing on the lower
deck allows for slight adjustments when fixture is mounted to ensure
fixture is centered over your canopy.
Once all four brackets are in place, use two people to lift the fixture
up to the mounting hardware. Slightly separate mounting hardware
until the black hooks slide over the light bar to securely grip the bar.
1
2
3
RACK
SUITABLE HANGING LOCATIONS
