SOLID DECKING MOUNTS CONTINUED
Left decking to loop each mount on the cross bar, positioned above light
bar located second from the end.
NOTE: do not attach mounting hardware to the end light bars.
Once all four brackets are in place, use two people to lift the fixture up to
the mounting hardware. Slightly separate mounting hardware until the
black hooks slide over the light bar to securely grip the bar.
Adjust SPYDR module to ensure full contact is made on the hooks of the
mounting hardware.
With all four mounting brackets attached to the SPYDR module, you can
adjust the mounting hardware along the cross bar or adjust the SPYDR
module along the contact points on the mounting hardware to center on
the 4’ x 4’ area.
2
3
4
5
