Recommended Test Equipment
5
Case, Top
Decal
Switch Assembly
Actuator, Switch
Main PCA
Shield, Bottom
Foot
LCD
Conn.
Elastomeric
Conn.
Elastomeric
LCD to PCA
Support, Switch Assembly
Battery
Shock Absorber
Case, Bottom
Screw, THD Form, PH.P.STL,
5-14 x .750
ig3f.eps
Figure 1. Model 16 Disassembled Unit

Fluke 16 Specifications

General

Type	Digital Multimeter
Continuity Check	Yes
Diode Test	Yes
Temperature Resolution	0.1 °C
Accuracy	±(0.5% + 1 digit)
Temperature Measurement	-40 °C to 400 °C
Capacitance Measurement	1000 µF
Battery Type	9 V
Battery Life	200 hours
Operating Temperature	0 °C to 50 °C
Storage Temperature	-20 °C to 60 °C
Emissivity	Not applicable
Distance to Spot Ratio	Not applicable
AC Voltage Range	0.1 mV to 600 V
DC Voltage Range	0.1 mV to 600 V
Resistance Range	0 - 40 MΩ
