Fluke 1736 Manual Supplement

Manual Supplement 1736/1738 Users
10 7/19
On page 55, Table 9, replace Ref. 7, 8, 9, and 10 with:
G
Test Leads 0.18 m blue, 1000 V CAT III 1 set 5016873
H
Test Leads 2 M, 2x alligator clips, blue,
1000 V CAT III
1 set 5020006
I
Cable marker 1 set 5046009
J
USB Flash Drive (includes Users
Manual, Fluke Energy Analyze Plus
software, and Software Licenses)
1 N/A
On page 56, replace Figure 11, with:
Figure 11. Replacement Parts

Fluke 1736 Specifications

General

Product type	Three phase power measurement logger
Cable lock slot type	Kensington
International Protection (IP) code	IP50
Operating altitude	0 - 4000 m
Non-operating altitude	0 - 12000 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Built-in display	Yes
Display diagonal	4.3 \
Touchscreen type	Resistive
Display resolution	480 x 272 pixels
Display technology	TFT
Efficiency	68.2 %
Battery life	4 h
Charging time	6 h
Battery voltage	3.7 V
Input frequency	50/60 Hz
Battery capacity	9.25 Wh
Power consumption (max)	50 VA
Battery life (power save mode)	5.5 h

Weight and Dimensions

Depth	55 mm
Width	198 mm
Height	167 mm
Weight	1100 g
Power adapter weight	400 g
Power supply dimensions (WxDxH)	130 x 45 x 130 mm
