Appropriate Usage
The instrument may only be used under those conditions and for those purposes for which it
was conceived. For this reason, in particular the safety references , the technical data including
environmental conditions and the usage in dry environments must be followed.
When modifying or changing the instrument, the operational safety is no longer ensured.
Operation Elements and Connections
Transmitter
1) Terminal "+"
2) Terminal "ground"
3) LCD
4) Key Sensitivity Level
Repeated pressing allows selection between
three transmission levels.
5) Key ON/OFF
To switch off the instrument press the button for
approx. 2 seconds.
6) Battery case (backside)
6 a) Jumper for selectable Code (in battery case)
Standard setup is "Code F”
