TS100 Cable Fault Finder
Users Guide
Safety Information
The following IEC symbols are used either on the test
set or in the manual:
WXWarning
If this product is used in a manner not
specified by the manufacturer, the
protection provided by the product may be
impaired.
Design Features
Design features of the TS100 Cable Fault Finder
include:
•
Easy to use
•
Tests all common cable pairs
•
Provides low cost protection against lost time due
to cable and connector problems
•
Single button operation
•
Up to 3000 feet (900 meters), dependent on cable
type
•
Accurate to ±2 feet (±1 meter) for short cables
•
Accurate to ±5 feet (±2 meters) for cables from
10 feet (3 meters) to 200 feet (60 meters) and ±3%
and ±5 feet (±2 meters) for cables longer than
200 feet (60 meters)
•
Bright 0.4 inch (1.016 centimeters) LED display
•
Up to 4 readings per second
•
Audible indication of shorted wires and external
voltage greater than 15 Vac
•
Automatic adjustments
•
Tone injection with the PowerTone™ positive
identification system
•
Input protected to 250 Vac
•
Components protected against damage from
moisture
•
Fifty hour battery life, intelligent auto-off
•
Low battery indicator
•
Uses 4 AA batteries (included)
•
High strength plastic (ABS) housing
W
Warning: Risk of personal injury. See the
manual for details.
Caution: Risk of damage or destruction to
equipment or software. See the manual
for details.
X
Warning: Risk of electric shock.
.
Earth ground
P
Conformité Européenne. Conforms to
relevant European Union directives.
)
CAN/CSA-C22.2 No. 60950-1-03
CAN/CSA-C22.2 No. 1010.1-92 + CSA-C22.2
No. 1010.1B-97, UL/ANSI 3111-1
~
Do not put products containing circuit
boards into the garbage. Dispose of
circuits boards in accordance with local
regulations.
