Ordering information
Fluke-434-II Three-Phase Energy Analyzer
Fluke-435-II Three-Phase Power Quality and Energy Analyzer
Fluke-437-II 400 Hz Three-Phase Power Quality and Energy Analyzer
Optional/replacement accessories
I430-FLEXI-TF-4PK 6000 A Fluke 430 Thin Flexi 61 cm (24 in) 4 pack
C437-II Hard Case 430 Series II with roller
C1740 Softcase for 174X and 43X-II PQ Analyzer
i5sPQ3 i5sPQ3, 5 A ac Current Clamps, 3-pack
i400s i400s AC Current Clamp
WC100 WC100 Color Localization Set
GPS430-II GPS430 Time Synchronization Module
BP291 Double capacity Li-ion battery (up to 16 hr)
HH290 Hanging hook for use on cabinet doors
Fluke Corporation
PO Box 9090, Everett, WA 98206 U.S.A.
Fluke Europe B.V.
PO Box 1186, 5602 BD
Eindhoven, The Netherlands
Fluke. Keeping your world up and running.
®
For more information call:
In the U.S.A. (800) 443-5853 or
Fax (425) 446-5116
In Europe/M-East/Africa +31 (0) 40 2675 200 or
Fax +31 (0) 40 2675 222
In Canada (800)-36-FLUKE or
Fax (905) 890-6866
From other countries +1 (425) 446-5500 or
Fax +1 (425) 446-5116
Web access: http://www.fluke.com
©2006, 2011 Fluke Corporation.
Specifications subject to change without notice.
Printed in U.S.A. 8/2011 2643006D D-EN
Pub ID 11858-eng
Modification of this document is not
permitted without written permission
from Fluke Corporation.
Flexible Current Probe i430 Flexi-TF specification
General specifications
Probe and cable material Alcryn 2070NC, reinforced insulation, UL94 V0, Color: RED
Couplings material Lati Latamid 6H-V0 Nylon
Probe cable length 610 mm (24 in)
Probe cable diameter 12.4 mm (0.49 in)
Probe cable bend radius 38.1 mm (1.5 in)
Output cable length 2.5 meters RG58
Output connector Safety BNC connector
Operating range -20 °C to +90 °C
Storage temperature -40 °C to +105°C
Operating humidity 15 % to 85 % (non condensing)
Degree of protection (Probe) IP41
Specifications
Current range 6000 A AC RMS
Voltage output (@1000 ARMS, 50 Hz) 86.6 mV
Accuracy ± 1 % of reading(@ 25 °C, 50 Hz)
Linearity (10 % to 100 % of range) ± 0.2 % of reading
Noise (10 Hz – 7 kHz) 1.0 mV ACRMS
Output impedance 82 Ω min
Load impedance 50 MΩ
Internal Resistance per 100 mm probe
length
10.5Ω ± 5 %
Bandwidth (-3dB) 10 Hz to 7 kHz
Phase error (45 Hz – 65 Hz) ± 1°
Position sensitivity ± 2 % of reading max.
Temperature coefficient ± 0.08 % max of reading per °C
Working voltage
(see safety standards section)
1000 V AC RMS or DC (head)
30 V max. (output)
