List of Replaceable Parts
3.4 Final Assembly Parts 3
3-5
Part or Kit Ordering Code Consists of Following Parts Figure/Item nr
Case)
Side Strap 3945370 Can be fixed on Left or Right side ---
Hang Strap 946769 Can be fixed op Top Side of
Instrument
---
Bottom Holster Set
43x-II
4161646 Bottom Holster assy 3-1/7
Cover for USB, yellow/black 3-1/10
Cover for right side, yellow 3-1/11
Connector Set 43x-II 4161654 Mini USB connector J1300 ---
Faston pin to battery (5 pcs/instr) ---
Cushion (Fits around faston pin) ---
Sealing piece USB, black (1
pce/instr)
3-2/25
Sealing piece, right side, black(1
pce/instr)
3-2/24
Battery Door Detection (opto device) 3-1/6
Power Connector DC ---
Keyboard connector 24p J1000 ---
LCD connector 20p J1201 ---
LCD backlight conn 4p J1200 ---
Keypad 43x-II 4161679 --- 3-2/26
Keypad Foil 43x-II 4161687 (Incl. Flat Cable) 3-2/20
Cable DB-9 to Mini-
USB
4161693 For use of GPS 430 option with Flk
43x-II
---
Input Socket Block
43x-II
4161668
BNC black (4 pcs/instr)
3-1/14
Banana jack black (4 pcs/instr)
---
Banana jack green (1 pce/instr)
---
O-ring 11x1 mm
---
O-ring 12x2 mm
---
Sealing strip, flexible, fits around
inputs
3-1/13
Note
Li-Ion
The Analyzer contains a Li-ion battery. Do not mix with the
solid wastestream. Spent batteries should be disposed of by a
qualified recycler or hazardous materials handler.
