Fluke 51 User Manual

51 & 52 Series II
Users Manual
6
Display Elements
xx
2
3
4
5
6
7
8
9
10
1
aas02f.eps
Figure 2. Display Elements
Table 4. Display Elements
A The thermocouple measurement includes an
offset. See "Changing Setup Options."
B The displayed readings do not change.
C A shift function is in progress.
D Setup is in progress.
E Low battery. Replace the batteries.
F Primary Display.
Model 51 : T1 reading.
Model 52: T1, T2, or T1-T2 reading.
G The temperature unit.
H Secondary Display: MAX, MIN, AVG, or offset.
Model 52: T1or T2 reading.
I The thermocouple type.
J Time Display: The elapsed time.
Downloaded from Elcodis.com electronic components distributor

Fluke 51 Specifications

General

Type	Digital Thermometer
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-20 °C to 60 °C (-4 °F to 140 °F)
Temperature Range	-200°C to 1372°C (-328°F to 2501°F)
Resolution	0.1°C
Thermocouple Type	K
Display	LCD
Battery Life	1000 hours
Battery Type	9V
