Fluke 63 User Manual

63/66/68
Display
7
Display
A
B
C
D
E
F
G
H
I
J
ame001.eps
A
Backlight “On” symbol (63/66/68)
B
°C/°F symbol (Celsius/Fahrenheit) (63/66/68)
C
High alarm and low alarm symbol (66/68)
D
Maximum temperature display (63)
Temperature values for the MAX, MIN, DIF, AVG, HAL,
LAL, PRB (66/68)
E
Icon for MAX (63/66/68)
Icon for MIN, DIF, AVG, HAL, LAL, PRB (66/68)
F
LOG icon shows log mode for data storage (66/68)
G
Live temperature value (63/66/68)
H
SCAN or HOLD (63/66/68)
I
Emissivity symbol and value (63/66/68)
J
Low Battery and Laser “On” symbols (63/66/68)
Lock symbol (66/68)

Fluke 63 Specifications

General

Accuracy	±1% of reading or ±1°C (±2°F), whichever is greater
Distance to Spot Ratio	8:1
Power	9V battery
Display Resolution	0.2°C (0.5°F)
Display	LCD
Emissivity	Preset to 0.95
Weight	227 g
