Fluke Ti40 - Page 109

Appendices
Camera Specifications and Dimensions D
D-7
Table D-2 lists the technical specifications for the TiR3, TiR4, Ti55 and Ti50
models.
Table D-2. TiR3, TiR4, Ti55 and Ti50 Specifications
Model Name
Ti55 and
TiR4 with
IR Fusion
Ti55 and TiR4
without
IR Fusion
Ti50 and
TiR3 with
IR Fusion
Ti50 and
TiR3
without
IR Fusion
Imaging Performance
Detector 320 x 240 Focal Plane Array (FPA), vanadium oxide (VOX)
uncooled microbolometer.
Refresh Rate Cameras have either 7.5 Hz or 60 Hz refresh rate. Use the
Camera Info screen to determine the refresh rate for your
specific camera.
Spectral Band 8 µm to 14 µm
Thermal
Sensitivity
≤ 0.050 °C at 30 °C ≤ 0.070 °C at 30 °C
Focusing Single Finger Manual Focus
Electronic Zoom 2x, 4x, 8x
(2x, 4x
when
Fusion
enabled)
2x, 4x, 8x 2x
Digital Image
Enhancement
Automatic Full-time Enhanced
Display and Image Storage
Digital Display 5 in high-resolution, 320 x 240, sunlight readable color LCD
