Fluke Ti40 - Page 110

TiR2,TiR3,TiR4,Ti40,Ti45,Ti50,Ti55
Users Manual
D-8
Table D-2. TiR3, TiR4, Ti55 and Ti50 Specifications (cont.)
Model Name
Ti55 and
TiR4 with
IR Fusion
Ti55 and
TiR4 without
IR Fusion
Ti50 and
TiR3 with
IR Fusion
Ti50 and
TiR3
without
IR Fusion
On-screen
Indicators
Indicate status of battery, target emissivity, background
temperature, temperature unit (C/F/K), date, and time
Palettes 8 unique color palettes available
Storage
Medium
Compact Flash Card (stores hundreds of images)
File Formats
Supported
14-bit measurement data included. Exportable JPEG, BMP,
TIF, PNG using SmartView desktop software
Image Controls Level, Span, Auto Adjust (continuous/manual)
Image Browsing Full-screen and thumbnail
Enhanced Text
Annotation
User definable,
automatically included in
reports
n/a
Programmable
Image Capture
Program camera to
automatically capture
thermal images
n/a
Standard Optics
20mm f/0.8
Germanium
Field of view—23 ° Horizontal x 17 ° Vertical (optional
lenses available)
Spatial
Resolution
(IFOV)
1.3 mrad IFOV, 0.15 m minimum focus
