Fluke Ti40 - Page 112

TiR2,TiR3,TiR4,Ti40,Ti45,Ti50,Ti55
Users Manual
D-10
Table D-2. TiR3, TiR4, Ti55 and Ti50 Specifications (cont.)
Model Name
Ti55 and TiR4
with
IR Fusion
Ti55 and
TiR4 without
IR Fusion
Ti50 and
TiR3 with
IR Fusion
Ti50 and TiR3
without
IR Fusion
Battery
Charging
2-bay intelligent charger powered via AC outlet or optional 12v
from car
AC Operation AC adapter 110/220 V ac,
50/60 Hz
Option
Power Saving Automatic shutdown and standby modes (user specified)
Interfaces
Video Output RS170 EIA/NTSC or CCIR/PAL composite video
Physical Characteristics (IR Fusion Model)
Weight 4.4 lbs including battery
Size 71mm x 262mm x 196mm (2.8 in x 10.5 in x 7.7 in)
Tripod
Mounting
1/4 in – 20 UNC
Environmental
Operating
Temperature
-10 °C to +50 °C (14 °F to 122 °F)
Storage
Temperature
-40 °C to +70 °C (-40 °F to 158 °F)
Humidity Operating and storage 10 % to 95 %, non-condensing
Shock/
Vibration
25G, IEC 68-2-29 / 3G, IEC 68-2-6
Encapsulation IP54, IEC 60529
