Fluke Ti40 - Page 114

TiR2,TiR3,TiR4,Ti40,Ti45,Ti50,Ti55
Users Manual
D-12
Table D-2. Ti R3, TiR4, Ti55 and Ti50 Specifications (cont.)
Model Name
Ti55 and
TiR4 with
IR Fusion
Ti55 and
TiR4 without
IR Fusion
Ti50 and
TiR3 with
IR Fusion
Ti50 and
TiR3
without
IR Fusion
Sun Shield
54-mm Tele-photo Lens (9 °H x 6 °V)
10.5-mm Lens (42 °H x 32 °V)
AC Adapter
Visible Light Camera
Pixels 1.3 M
Active Pixels 1280 H x 1024 V
Field of View 56° H x 46° V
Sensitivity 1 lux
Focus
Distance
50 cm to infinity
Exposure Auto
Integrated
Flash
Manual or default for high quality visible light images
Torch Light
Mode
For enhanced video imaging in dark areas
IR Fusion
Modes
• Full screen IR image
blended with visible image
• Picture-in-picture blended
with visible image
• Alarm mode
• Full screen IR image
blended with visible image
• Picture-in-picture blended
with visible image
• Alarm mode
