Appendices
Camera Specifications and Dimensions D
D-13
Camera dimensions are shown in Figures D-1 and D-2.
7.11 cm
(2.8 in)
10.66 cm
(4.2 in)
eii019.eps
Figure D-1. Camera Dimensions
26.67 cm
(10.5 in)
19.55 cm
(7.7 in)
eii020.eps
Figure D-2. Camera Dimensions - Height and Width
