Fluke Ti400 - Features and Controls (Part 1); Imager Components (1-9)

Thermal Imagers
Features and Controls
11
Features and Controls
Table 3 shows the Imager features and controls.
Table 3. Features and Controls
Ti200
IR FUSION
TECHNOLOGY
11
10
9
6
7
8
4
5
12
13
3
1
2
hie01.eps
Item Description
 HDMI Connection
 USB Cable Connection
 Microphone
 Speaker
 LCD Display
  Power On/Off
 Function Buttons (F1, F2, and F3)

Arrow Buttons

Lithium-ion Smart Battery
