Installation drawing
Selection of location
Basic requirement
Installing the unit in the following places maycause malfunction. If it is unavoidable, please
consult the local dealer:
1. The place with strong heat sources,vapors,ammable or explosive gas,or volatile objects
spread in the air.
2. The place with high-frequency devices (such as welding machine,medical equipment).
3. The place near coast area.
4. The place with oil or fumes in the air.
5. The place with sulfureted gas.
6. Other places with special circumstances.
7. The appliance shall not be installed in the laundry.
Indoor unit
1. There should be noobstruction near air inlet and air outlet.
2. Choose a place where the condensation water can be dispersed easily and won't affect
other people.
3. Choose a place which is convenient to connect the outdoor unit and near the power
socket.
4. Choose a place which is out of the reach of children.
5. The place should be ableto withstand the weight of indoor unit and won't increase noise
and vibration.
6. The appliance must be installed 2.5m above oor.
7. Don't install the indoor unit right above the electric appliance.
8. Please try your best to keep way from uorescent lamp.
At least 250cm
At least 15cm
Space to the ceilin
