Fluo FSS101EI/JDF-N3 - Installation of Indoor Unit

24
Step 1: Choosing installation location
Recommend the installation location to the client and then conrm it with the client.
Step 2: Install wall-mounting frame
1. Hang the wall-mounting frame on the wall; adjust it in horizontal position with the level
meter and then point out the screw xing holes on the wall .
2. Drill the screw xing holes on the wall with impact drill (the specication of drill head
should be the same as the plastic expansion particle) and then ll the plastic expansion
particles in the holes.
3. Fix the wall-mounting frame on the wall with tapping screws (ST4.2X25TA) and then
check if the frame is rmly inatalled by pulling the frame. If the plastic expansion particle
is loose, please drill another xing hole nearby.
Step 3: Open piping hole
1. Choose the position of piping hole according to the direction of outlet pipe. The position
of piping hole should be a little lower than the wall-mounted frame, shown as below.
Left
Wall
Φ55/Φ70
Right
Mark in the middle of it
Level meter
Rear piping hole
Wall
Space
to the
wall
above
150mm
Space
to the
wall
above
150mm
Φ55/Φ70
Rear piping hole
Dimension: 1081x327x248
Left
Wall
Φ55
Right
Mark in the middle of it
Level meter
Rear piping hole
Wall
Space
to the
wall
above
150mm
Space
to the
wall
above
150mm
Φ55
Rear piping hole
Left
Wall
Φ55
Right
Mark in the middle of it
Level meter
Rear piping hole
Wall
Space
to the
wall
above
150mm
Space
to the
wall
above
150mm
Φ55
Rear piping hole
Dimension: 721x274x195 Dimension: 792x279x195
Left
Wall
Φ55
Right
Mark in the middle of it
Level meter
Rear piping hole
Wall
Space
to the
wall
above
150mm
Space
to the
wall
above
150mm
Φ55
Rear piping hole
Left
Wall
Φ55/Φ70
Right
Mark in the middle of it
Level meter
Rear piping hole
Wall
Space
to the
wall
above
150mm
Space
to the
wall
above
150mm
Φ55/Φ70
Rear piping hole
Dimension: 850x291x203
Dimension: 972x302x224
Installation of indoor unit
