Flycam 5000 - Mount Camera Setup

4
• Aach your camera setup (Not Included) to
the adapter and ghten the lever back.
• Open the lever and remove the quick release
plate from the adapter. Then aach it to
your camera (Not Included) using a
screwdriver (Not Included)
• Remove the Head plate from the 3-piece
Head assembly to aach it to your camera
(Not Included). You will note several
mounng holes to adapt various cameras.
NOTE: If you wish to bypass Quick Release Plate, the camera can be directly aached to Head Plate by
following this assembly sequence:
• Keep the camera (Not Included) in the center
of the Head Plate and secure it properly. Do
not over-ghten this adjustment as it can
break the threaded insert.
• The many slots located on Head Plate and
Boom Plate allow you to easily adjust X & Y
-Axis for perfect balance. As shown, place
the assembly in line with the center of the
stabilizer post and ghten the side adjusters.
Further ne-tuning will probably be
required.
Images showing Head Plate X adjustment
Images showing Head Plate Y adjustment
