18
Step 10: Install running boards
A. Identify the right and left running boards before assembling using the stickers
on the underside of the wood boards.
B. Using the provided 5mm allen key, remove the screw and washers from the
rear frame. Set aside.
C. Align the running board brackets with the threaded inserts on the frame.
D. Reinstall the screws and washers using the provided 5mm allen key.
Tighten the screw to 10Nm.
B
D
C
