Flymo EasiLife GO User Manual

8. Remove the battery.
9. Disconnect the cable to the battery.
10. Connect the cable to a new battery.
11. Put the new battery into position in the product.
12. Install the battery holder and the screw.
13. Remove the sealing strip in the upper chassis.
14. Install a new sealing strip in the upper chassis. Put
one end of the sealing strip in line with the mark on
the chassis.
CAUTION:
Install a 5 mm sealing
strip. An incorrect dimension of the
sealing strip or an incorrect installation
can cause leakage.
15. Put the sealing strip clockwise around the lower
chassis.
16. Put the other end of the sealing strip above the first
end and then out of the channel.
17. Attach the sealing strip in the retainer.
18. Install the upper chassis and attach the 10 screws
with a Torx 20 (Screw torque 1.8 Nm).
5.7 Winter service
Take your product to your Flymo service for service prior
to winter storage. Regular winter service will maintain
the product in good condition and create the best
conditions for a new season without any disruptions.
Service usually includes the following:
• Thorough cleaning of the body, the chassis, the
blade disc and all other moving parts.
• Testing of the product’s function and components.
• Checking and, if required, replacing wear items
such as blades and bearings.
• Testing the product’s battery capacity as well as a
recommendation to replace battery if necessary.
• If new firmware is available, the product is
updated.
30
- Maintenance 1622 - 001 - 03.03.2021

Flymo EasiLife GO Specifications

General

Model	EasiLife GO
Category	Lawn Mower
Type	Robotic
Cutting Width	16 cm
Cutting Height Range	20-50 mm
Battery Type	Lithium-Ion
Battery Voltage	18 V
Battery Capacity	2.0 Ah
Area Capacity	400 m²
