4. Push the grass box handle (14) into the grass
box cover (13) until the connections click.
To assemble the grass box lid
1. Put the grass box lid (12) in the mower body
(10).
Operation
Before you do operation
WARNING!
• Risk of physical injury!
• Cut injury when the blade turns or
the product starts accidentally.
• Wait for the blade to stop, disconnect
the product from the mains and use
gloves before you connect or
transport the product.
To connect the mower
WARNING!
• Risk of electric shock!
• To avoid damage to the mains cable,
the mains cable must be inserted into
the cable lock (L).
• Before you operate insert the mains
cable into the cable lock (L)
1. Loop the mains cable, insert the loop into the
cable lock (L) and pull tight.
2. Connect the mains cable into a 230 V mains
socket.
To start the mower
WARNING!
• Risk of physical injury!
• Risk of injury if the product does not
stop when you release the start
lever.
• Do not bypass the safety devices or
switches. For example do not attach
the start lever (22) to the handle.
To start:
The product is fitted with a two-handed safety device
(start lever (22) with safety interlock (23)) to prevent
the product from being turned on by accident.
There are two start levers (22) fitted. Either one have
to be used to start.
1. Connect the mains cable into a 230 V mains
socket.
2. Push the safety interlock (23) with one hand and
pull the start lever (22) with the other hand.
3. Release the safety interlock (23).
The product will start.
To stop:
1. Release the start lever (22).
10
17 - 001 -
