Flymo Glider Compact 330 VC User Manual

Product overview
17
2
3
1
4
14
15
16
5
2 x
6
2 x
7
3 x
8
4 x
18
13
12
11
10
9
19
1. Push button
2. Wing knob
3. Cable hook knob
4. Cable hook pin
5. Bolt
6. Washer (2 x)
7. Cable clip (3 x)
8. R-clip (4 x)
9. Lower handle
10. Mower body
11. Grass box chute
12. Grass box lid
13. Grass box cover
14. Grass box handle
15. Upper handle
16. Middle handle
17. Bumper
18. Cable connector
19. Grass box
4 17 - 001 -

Flymo Glider Compact 330 VC Specifications

General

Brand	Flymo
Model	Glider Compact 330 VC
Category	Lawn Mower
Language	English
