Cables
If extension cables are used, these must comply with the
minimum cross- sections in the table below:
Voltage Cable length Cross section
220 – 240 V / 50 Hz Up to 40 m 1.0 mm
2
220 – 240 V / 50 Hz Up to 60 m 1.5 mm
2
220 – 240 V / 50 Hz Max. 100 m 2.5 mm
2
Minimum rating:
1.0 mm
2
size cable, 10 amps 250 volts AC.
Your product is supplied with cable wired directly
into the product.
1. If the supply cord is damaged, it must be replaced by
your local Husqvarna UK Ltd. Approved Service Cen-
tre or similarly qualified persons in order to avoid a
hazard.
2. Flymo Extension Cables are available from your local
Husqvarna UK Ltd. Approved Service Centre.
3. Do not wire an extension cable directly to your product
yourself. Please contact your local Husqvarna UK Ltd.
Approved Service Centre for further information on the
connectors and kits available.
4. Only use extension cables specifically designed for
outdoor use and which conform to one of the follow-
ingspecifications: Ordinary rubber (60245 IEC 53),
Ordinary PVC (60227 IEC 53) or Ordinary PCP
(60245 IEC 57).
Connectors – Important
• Flymo connectors are suitable for use with 2 core
cable only. Under no circumstances should these
connectors be used for earthed products.
• All Flymo connectors and cables are of splashproof
construction. They are not waterproof and must not
be left outside permanently nor should they be sub-
merged or immersed in water. Do not let cable lay or
trail through pools of water or splashed with water
from hose pipes.
Mains plug replacement – Important
• If the plug supplied is cut off it should be
destroyed. There is an electric shock hazard if
a cut off plug is inserted into a 13 amp socket.
1. No earth required. Flymo products are double insulat-
ed to EN60335 and under no circumstances should
an earth be connected to any part of the product.
2. Ensure the mains voltage suits your product.
3. Important! The wires in the mains lead are coloured
in accordance with the following code:
BLUE – NEUTRAL; BROWN – LIVE.
The wire which is coloured BLUE must be connected
to the Terminal which is marked with the letter 'N' or
coloured BLACK. The wire which is coloured BROWN
must be connected to the Terminal which is marked
with the letter 'L' or coloured RED.
4. It is important that the outer sheath is clamped
correctly into the 3-pin plug.
5. If in doubt consult your local Service Repairer or
qualified electrician before the machine is used.
6. A 13 Amp fuse must be fitted to the Mains Plug.
7. The normal plug fuse and household fuse only protect
the electrical equipment and are not a safeguard
against electrocution.
Training
1. Read the instructions carefully. Be familiar with the
controls and the correct use of the machine.
2. Never allow children or people unfamiliar with these
instructions to use the machine. Local regulations can
restrict the age of the operator.
3. Never operate the machine while people, especially
children, or pets are nearby.
4. Keep in mind that the operator or user is responsible
for accidents or hazards occurring to other people or
their property.
Preparation
1. While operating the machine always wear substantial
footwear and long trousers. Do not operate the
machine when barefoot or wearing open sandals.
Avoid wearing clothing that is loose fitting or that
hanging cords or ties.
2. Thoroughly inspect the area where the machine is to
be used and remove all objects which can be thrown
by the machine.
3. Before using, always visually inspect to see that the
blade, blade bolt and the blade assembly are not worn
or damaged. Replace worn or damaged components
in set to preserve balance. Replace damaged or
unreadable labels.
4. Before use check the supply and extension cord for
signs of damage or ageing. If the cord becomes dam-
aged during use, disconnect the cord from the supply
immediately. DO NOT TOUCH THE CORD BEFORE
DISCONNECTING THE SUPPLY. Do not use the
machine if the cord is damaged or worn.
Operation
1. Operate the machine only in daylight or in good
artificial light.
2. Avoid operating the machine in wet grass.
3. Always be sure of your footing on slopes.
4. Walk, never run.
5. Mow across the face of slopes, never up and down.
6. Exercise extreme caution when changing direction on
slopes.
7. Do not mow excessively steep slopes.
8. Use extreme caution when reversing or pulling the
machine towards you.
9. Stop the blade(s) if the machine has to be tilted for
transportation when crossing surfaces other than
grass, and when transporting the machine to and
from area to be used.
10. Never operate the machine with defective guards or
shields, or without safety devices, for example deflec-
tors and/or grass collector, in place.
11. Switch on the motor carefully according to instruc-
tions and with feet well away from the blade(s).
12. Do not tilt the machine when switching on the motor,
except if the machine has to be tilted for starting. In
3
