Flymo Glider Compact 330AX User Manual

2. ASSEMBLY
WARNING! Risk of physical injury!
Cut injury when the blade turns or the product starts
accidentally.
v Wait for the blade to stop, disconnect the product from
the mains and use gloves before you do assembly.
To assemble the grass box:
1
2
3
4
1. Push the grass box handle
2
into the grass box cover
1
until the
connections click.
2. Put the grass box lid
3
in the mower body
4
.
5

Flymo Glider Compact 330AX Specifications

General

Type	Push lawn mower
Noise level	87 dB
Cutting width	330 mm
Product color	Black, Orange
Number of wheels	2 wheel(s)
Maximum lawn area	- m²
Mulching function	-
Maximum cutting height	32 mm
Minimum cutting height	12 mm
Grass collecting volume	22 L
Cutting clearance adjustment	Yes
Power source	AC
UK Trade Tariff code	8433111000

Weight and Dimensions

Depth	1390 mm
Width	420 mm
Height	750 mm
Weight	9400 g
Package depth	810 mm
Package width	430 mm
Package weight	11100 g
