Keep hands clear of the propellers during battery installation and removal.
Remove nose cone. Use two
ngers to secure connector during
battery installation and removal.
Press battery into
place to secure.
Replace nose cone.
Right stick moves left, left aileron moves
up and right aileron moves down, causing
the aircraft to bank to the left.
Left stick moves left, rudders move
left, causing the aircraft to yaw left.
Nosewheel points left.
Right stick moves down, elevator moves up
causing the aircraft’s nose to pitch up.
8
INSTALLATION AND REMOVAL OF THE LIPO BATTERY
CHECK THE CONTROL SURFACE DIRECTION
Disconnect and remove the battery after each flight by holding the battery lead with two fingers and removing the battery
from the lead with the other hand. Do not yank or jerk the battery from the aircraft. This could dislodge the RX board
from the Micro B-25 Mitchell.
