SAFETY PRECAUTIONS
THIS RADIO CONTROL MODEL IS NOT A TOY! PLEASE OBSERVE THE FOLLOWING CAREFULLY:
♦
FIRST-TIME BUILDERS SHOULD SEEK ADVICE FROM PEOPLE HAVING BUILDING EXPERIENCE IN
ORDER TO ASSEMBLE THE MODEL CORRECTLY AND ENSURE SUCCESSFUL OPERATION.
♦
ASSEMBLE THIS KIT ONLY IN PLACES OUTSIDE THE REACH OF CHILDREN.
♦
FOLLOW ALL ASSEMBLY AND SAFETY INSTRUCTIONS CONTAINED WITHIN THIS MANUAL TO
ENSURE SAFE OPERATION.
♦
NEVER FLY RADIO CONTROL MODELS IN CONGESTED AREAS OR CLOSE TO POWER LINES
♦
USE CAUTION WHEN STARTING THE MOTOR - KEEP HANDS CLEAR OF PROPELLER AT ALL
TIMES - ESPECIALLY DURING LAUNCH.
♦
FMA, INC. WILL NOT ACCEPT ANY LIABILITY RESULTING FROM FAILURE TO ASSEMBLE AND
OPERATE THIS MODEL AIRPLANE IN ACCORDANCE WITH THE RAZOR ASSEMBLY AND
OPERATIONS MANUAL.
♦
IN SOME AREAS OF THE COUNTRY IT IS NOT LEGAL TO FLY AT FIELDS OTHER THAN APPROVED
R/C FLYING FIELDS. CHECK WITH AUTHORITIES IN YOUR AREA, JOIN YOUR LOCAL CLUB.
♦
FMA, INC. RECOMMENDS MEMEBERSHIP IN AMA (ACADEMY OF MODEL AERONAUTICS) FOR
PURPOSES OF INSURANCE - PLEASE CONTACT LOCAL AMA CHARTER FOR DETAILS.
!
The product you have purchased is powered by a rechargeable battery. The battery is recyclable. At the
end of its useful life, under various national, state, and local laws, it may be illegal to dispose of this
battery into the municipal waste stream. Check with your local solid waste officials for details in your area
for recycling options or disposal.
PACKAGE CONTENTS
Carefully unpack the contents of your RAZOR kit and lay the parts out on a clean workspace, ready for assembly.
Identify your kit and verify that it contains the items listed in the following table. Note: if you discover that
something is missing or damaged, please contact the authorized FMA Direct dealer where you purchased the
product or phone FMA Direct at (301) 668-7614.
MODEL: CONTAINS: CONTAINS: CONTAINS:
RZRSLPKIT/RZR400KIT
1 LEFT, 1 RIGHT WING
1 ELEVON PACK 2 ELEVONS
1 WINGLET PACK 2 WINGLETS
1 400 PLASTICS PACK 1 400 TRAY, 1 CANOPY
1 HARDWARE PACK 1 PUSHROD PACK 1 LEFT, 1 RIGHT PUSHROD
1 CONTROL HORN PACK 2 CONTROL HORNS, 4 SCREWS
1 MTL CLEVIS PACK 2 CLEVIS, 2 RETAINING CLIPS
ELEVON TAPE 2 PCS. 0.005” LEXAN W/ ADHESIVE
STRUCTURAL TAPE 4 PCS. 0.010” LEXAN W/ ADHESIVE
SCREEN CLOTH 1 2” X 4” 120 GRIT
MOTOR TIE 1 8” X 0.142” NYLON TIE
HOOK & LOOP TAPE 1 5/8” X 2” MALE AND FEMALE
1 22” 5.5mm CARBON SHAFT
OWNER’S MANUAL
RZRSLPRTF1
RZRSLPKIT CONTENTS PLUS:
1 MICRO RCVR FM OR AM
2 S80, S100 OR PS30 SERVOS
1 MICRO SWITCH HARNESS
1 4 CELL 110 mAh BATTERY
RZR400RTF1
RZR400KIT CONTENTS PLUS:
1 400 MOTOR PACK (ASSY) 1 400 CLASS 6V MOTOR
2 0.01UF CAPACITORS
1 MINI 20 ESC
1 SHOTTKY DIODE
1 TAMIYA MALE CONNECTOR
1 PROPELLER (5.5 X 4)
1 400 PROP ADAPTER 1 ADAPTER SHAFT
1 SPINNER
2 HEX SET SCREWS
1 7 CELL 600AE POWER PACK
RZR400RTF2
RZR400RTF1 CONTENTS PLUS:
1 MICRO RCVR FM OR AM
2 S80, S100 OR PS30 SERVOS
