Page 13 • MNFG003
Issue/Rev. 0.0 (2/10)
Section V – Diagnostics
If there are active alarms, they will be displayed as follows:
The active alarms can be cleared from this display by moving the arrow to the alarm and pressing "ENTER." The
microFlow.net Gas will then ask for the passcode. When the passcode is entered, the alarm will clear.
Pressing the CLEAR key will return the system to the Diagnostic menu.
Alarm History
The Diagnostics menu provides the selection "Alarm History" where the most recent alarms can be viewed. With
the arrow in front of "Alarm History," press ENTER, and the historical alarms will be displayed. The alarms will be
listed in order of occurrence.
This is an alarm history for the transaction. For a more complete history of alarms, please access the Event Log.
Pressing the up and down arrow keys will allow the operator to page through the Alarm History displays. If "More…"
is not displayed, then there is only one screen of alarms in the alarm history.
Pressing the CLEAR key will revert to the Diagnostic menu.
Event Log
The View Only Diagnostics menu displays "Event Log" where past events can be viewed. With the arrow in front of
"Event Log," pressing ENTER will display the last event that occurred in the microFlow.net Gas. The "Event Log"
includes alarms, transaction start and end, and program mode parameter changes.
From the display, the operator can go back through the events using the up and down arrow keys. Pressing the
CLEAR key will display the Diagnostics menu.
Batch Record Log
This diagnostic shows the selected batch data such as Batch Volumes, Averages and Non-Resettable Totalizers.
Active Alarms
- > PA: Power Fail Alarms
Alarm History
PA: Power Fail Alarm
DA: Mtr Program Error
PA: Power Fail Alarm
Event #621
03/12/99 0:59:02
Alarm Cleared -
DA: Mtr Program Error
Batch Record Log
Enter # of Batches Back
-->
To Next Page
