Ultrasonic Diagnostics
Ultrasonic Data
The values shown on these screens are provided by the ultrasonic meter. The microFlow.net Gas collects this infor-
mation from the ultrasonic meter via communication on a periodic basis.
For all of these screens, if communications to the Ultrasonic meter fails, the values shown will be all XXX’s.
Using the Up and Down arrow keys select the diagnostic:
SW Version – Identifies the software running in the ultrasonic meter.
Press Clear to return to the Ultrasonic Data Diagnostic Menu.
Status – This screen indicates the following statuses:
Software Version
microFlow Rev 00.00
CRC 850CCEE B
Bootloader Rev 00.02
MAC 00:50:C2:XX:XX:XX
Copyright 2007-2009
FMC Technologies Inc.
Ultrasonic Data
SW Version
Status
Path Info
Flow
Profile
Line Cond.
Alarms
SW Version
SW Version 1.05
SW Build XXXXXXXX
SW CRC XXXXXXXXX
Copyright 2007
FMC Technologies Inc.
Status
Log Count XXXXXXXX
Alarm Status XXXXXXXX
MID Mode Yes
HW Interlock Locked
DB Checksum XXXXXXXX
