Section V – Diagnostics
Clear the timer by writing a zero to the database location of the desired timer.
Using the up and down arrow keys will display the remaining timers. Pressing CLEAR will return to the Boolean/Al-
gebraic Processing menu. Pressing CLEAR again will return the display to the Display menu.
Batch Log Stats
This diagnostic shows the actual number of Batch Records currently stored and the maximum number that can be
stored.
Pressing CLEAR will return to the Diagnostics menu.
Summary Data
This menu gives the totals for the batch running. It displays how much was delivered and the associated pulses
from the meter for the batch in progress. If a new batch is started, only the current batch information will be shown.
Software Version
The Diagnostics menu provides the selection "Software Version," which allows the operator to view the version of
software that is running in the microFlow.net Gas. With the arrow in front of "Software Version," pressing ENTER will
display the software version, CRC, and MAC address.
Summary Data
GV 0.0 MCF
GSV 0.0 MCF
Temp IN 0.00 C
Mtr Count 0
Error Count 0
Alarm Occurred
Timer Numbers Resolution Range
1-2 0.1 second 109 minutes
3-4 1.0 second 18.2 hours
5-6 1.0 minute 45.5 days
7-8 1 hour 7.5 years
General Purpose Timers
#1 0 #7 0
#2 0 #8 0
#3 0
#4 0
#5 0
#6 0
Batch Log Stats
Actual # Stored 16
Max # Stored 2047
