FMC Technologies Smith Meter microFlow.net Gas - Page 28

Issue/Rev. 0.0 (2/10)
MNFG003 • Page 24
Where:
Log Count XXXXXXXX - Incremented by the meter each calculation cycle
Alarm Status XXXXXXXX - Bit encoded, if zero no alarms present on meter
MID Mode Yes/No - European MID mode indicator
HW Interlock Locked/Unlocked - Sealing jumper installed
DB Checksum XXXXXXXX - Configuration database checksum
Press Clear to return to the Ultrasonic Data Diagnostic Menu.
Path Info – Indicates current data from the paths of the Ultrasonic Meter
Provides the flow velocity of the fluid at each path of the ultrasonic meter:
Press CLEAR to return to the Path Info display.
Provides the velocity of sound for each path of the ultrasonic meter.
Press CLEAR to return to the Path Info display.
Provides the velocity of sound for each path of the ultrasonic meter.
Press CLEAR to return to the Path Info display.
Section V – Diagnostics
VOS
Path 2 00000000
Path 2 00000000
Path 3 00000000
Path 4 00000000
Path 5 00000000
Path 6 00000000
Path Info
- > Flow Velocity
VOS
SIG % 1-3
SIG % 4-6
GAIN 1-3
GAIN 4-6
Flow Velocity
Path 1 00000000
Path 2 00000000
Path 3 00000000
Path 4 00000000
Path 5 00000000
Path 6 00000000
