Section V – Diagnostics
Digital Outputs
The Diagnostics menu provides the selection "Digital Outputs" where the function and status of the digital outputs
can be viewed. With the arrow key in front of "Digital Outputs," pressing ENTER will display all six digital outputs
and their status.
Pressing the CLEAR key will display the Diagnostics menu.
Analog Inputs
The Diagnostics menu provides the selection "Analog Inputs," where the function and status of the analog inputs
can be viewed. With the arrow in front of "Analog Inputs," pressing ENTER will display the two analog inputs, their
current reading in engineering units, current, or voltage, and raw analog input value.
Pressing the CLEAR key will display the Diagnostics menu.
Pulse Inputs
The Diagnostics menu provides the selection "Pulse Inputs" where the meter pulses and the metered injector pulses
are displayed. With the arrow in front of "Pulse Inputs," pressing ENTER will display the pulse inputs.
Pressing the CLEAR key will display the Diagnostics menu.
Communications Monitor
The Diagnostics menu provides the selection "Comm Monitor" to review messages being sent and received across
the communications lines. With the arrow in front of "Comm Monitor," pressing ENTER will display the following:
Comm Monitor Live
- > comm 1
comm 2
comm 3
Digital Outputs
#1 N/A OFF
#2 N/A OFF
#3 N/A OFF
#4 N/A OFF
#5 N/A OFF
#6 N/A OFF
Analog Inputs
#1: M1 Temp In 15.0 C
14.062 mA 36863
#2: M1 Pressure 6.2 Kg/cm
2
16.170 mA 42388
#1 Cal:0131072 0917504
#2 Cal:0131072 0917504
Pulse Inputs
Fwd Count 0
Rev Count 0
Err Count 0
