Section V – Diagnostics
Press Clear to return to the Ultrasonic Data Diagnostic Menu.
Profile – Indicates current meter profiles
Press Clear to return to the Ultrasonic Data Diagnostic Menu.
Line Cond. – Indicates current temperature and pressure
Press Clear to return to the Ultrasonic Data Diagnostic Menu.
Alarms – Indicates current meter alarms; if no alarms are present the display will indicate:
Alarms available:
HIGH_FLOW
ELECTRONICS FAILURE
TRANSDUCER FAILURE
CALCULATION ERROR
SIGNAL LOW ALARM
GAIN ERROR ALARM
VOS DIFFERENCE ALARM
PATH SUBSTITUTION ALARM
PARAMETER ERROR
SOUND TO NOISE RATIO LOW
HIGH TURBULENCE ALARM
PROFILE DEVIANCE ALARM
Press Clear to return to the Ultrasonic Data Diagnostic Menu.
Press Clear to return to the Diagnostic Menu.
Contrast Adjust
This diagnostics menu provides for adjusting the display contrast.
Press CLEAR to return to the Diagnostics Menu.
Press CLEAR to return to the Main Menu.
Profile
Flatness 00000000
Symmetry 00000000
Swirl 00000000
Cross 00000000
Line Cond.
Temperature XXX.XX
Pressure XXXXX.XX
Alarms
--> No Alarms Present
Screen Contrast Adjustment
Press Up/Down Arrows to adjust contrast
