Transmitter Battery Installation
Before operation, install the battery and connect the system as instructed below.
Getting Started
使用前准备
开始操作前，请按照本章的顺序和指引安装电池、连接设备。
发射机电池安装
Danger Only use specified battery (X4 AAA batteries).
危险
仅使用厂家指定的电池。
请勿打开、拆卸或自行维修电池。
Danger Do not open, disassemble, or attempt to repair the battery.
危险
请勿挤压、刺穿或接触电池的金属端子。
Danger Do not crush/puncture the battery, or short the external contacts.
危险
请勿将电池置于高温环境或液体中。
Danger Do not expose to excessive heat or liquids.
危险
Danger Do not drop the battery or expose to strong shocks or vibrations.
危险
请注意防止电池跌落、碰撞或振动。
Danger Always store the battery in a cool, dry place.
危险
请将电池存放在干燥阴凉的环境中。
Danger Do not use the battery if damaged.
危险
如果电池损坏，请立即停止使用。
Battery Type: AAA
Follow the steps below to install the batteries:
1. Open the battery compartment cover.
2. Insert 4 AAA batteries with the correct polarity. Make sure it is connect-
ed with the correct polarity to avoid damage.
3. Replace battery compartment cover.
Low battery alarm: When the battery is lower than 4.2V, the transmitter
will give a alarm with the LED flashing slowly.
*Note: When installing the batteries, be careful to handle the positive and
negative poles. (As shown in the picture on the right)
电池类型使用：AAA 电池
请按照以下步骤安装发射机电池：
1. 打开电池仓盖。
2. 将 4 颗电量充足的 AAA 电池装入电池仓内，注意正负极方向并确保电
池上的金属端子与电池仓内的金属端子接触。
3.盖好电池仓盖。
低电量报警：当电量低于 4.2V 时，发射机即发出声音报警同时 LED 慢闪
*注：安装电池时，请留意电池正负极，避免安装错误。( 如右图所示 )
[17] Left Turn Signal Light Interface
[18] Right Turn Signal Light Interface
[19] Tail Light Interface
[20] Brake Light Interface
[21] Backup Light Interface
[22] Signal Pin
[23] + (CH Interface/Light Interface Anode)
[24] - (CH Interface/Light Interface Cathode)
