14
Follow the steps below to turn off the system:
1. Disconnect the receiver power.
2. Toggle the transmitter's power switch to the off position.
This function is used to set the neutral position for throttle and wheel.
Every transmitter is calibrated before leaving the factory, however if recalibration is required,please
follow these steps:
1. Turn and hold the wheel as far clockwise as it will turn, hold the throttle all the way forward, then turn
on the transmitter in calibration mode.
• The R.LED and G.LED will flash twice. • The RX.BATT LED will be solid on in yellow.
2. Calibrate steering wheel: Turn the steering wheel to max and min travel point in clockwise and
counterclockwise.
• The R.LED will be off. • The RX.BATT LED will be solid on in red.
3. Throttle trigger calibration: Push/pull the throttle trigger to forward/backward as far as it will go.
• When the calibration is completed, the G.LED will be off.
• The RX.BATT LED will be solid on in green.
4.Both steering wheel and throttle trigger have finished the calibration.
• The RX.BATT LED will be off.
5. Once the calibration is finished, press the BIND button to save and exit.
Power Off
关机
Stick Calibration
摇杆校准
请按照以下步骤进行关机：
1. 断开接收机电源 ;
2. 将电源开关拨到 [OFF] 位置，使发射机关闭。
该功能可以用于方向手轮和油门扳机的中位角度修正。
发射机在出厂前已校准完成，如需要重新校准，请按照以下步骤执行。
1. 同步将手轮顺时针打到最大、扳机往前推到底并开机，进入校准模式功能；
• R.LED 指示灯和 G.LED 指示灯二闪一灭 • RX.BATT 指示灯黄色常亮
2. 方向手轮校准:将手轮顺时针和逆时针转到最大最小；
• R.LED 指示灯灭 • RX.BATT 指示灯红色常亮
3. 油门扳机校准：将扳机向前向后推到最大和最小；
• G.LED 指示灯灭 • RX.BATT 指示灯绿色常亮
4. 方向手轮油门扳机均校准通过；
• RX.BATT 指示灯灭
5. 校准完成后按“BIND”键退出并保存数据。
Danger
Make sure to disconnect the receiver power before turning off the transmitter. Failure to
do so may lead to damage or serious injury.
危险
关闭时，请务必先关闭接收机电源，再关闭发射机，否则可能导致模型损坏、人员受伤。
Instructions
操作指引
