The transmitter outputs a total of 4 channels, which are assigned as below, as well as the functions.
• CH1 Channel: The assigned control is the steering wheel. CH1 controls the steering to enable a car to
turn left or right.
• CH2 Channel: The control is the throttle trigger. CH2 controls the throttle to enable a car to move
forward or backward.
• CH3 Channel: The control is the CH3 three-position switch. Users can customize the channel function.
For example, function as a fast /slow-position servo channel.
• CH4 Channel: The control is the CH4 button switch. Users can customize the channel function. For
example,control the car lights (short-press to switch the car light mode), and switch the drive control/
four-wheel steeringfunction.
15
Channel Description
通道说明
Channel Reverse
通道反向
Trims
微调
System Functions
系统功能
该发射机共输出 4 个通道，控件分配和相应功能如下：
• CH1 通道：控件为方向手轮，功能为方向，控制车子左右转向。
• CH2 通道：控件为油门扳机，功能为油门，控制车子前后行驶。
• CH3 通道：控件为 CH3 三档开关，可自定义通道功能，如可作为快慢档舵机通道。
• CH4 通道：控件为 CH4 按键开关，可自定义通道功能，如可控制车灯（短按切换车灯工作模式）、可切换
驱动控制 /四轮转向功能。
This function is used to adjust the action direction of the servo or motor
The ST.REV / TH.REV switches are the reverse buttons for CH1 and CH2. If the switch is up it indicates
reverse, and the down indicates normal.
The ST.TRIM switch is used to adjust the trim for CH1 (steering), and can also adjust the trim for CH3 as
multiplexing mode. The TH.TRIM switch is used to adjust the trim for CH2(throttle), and can also adjust the
trim for CH4.
Refer to [Mode Switching] for multiplexing switching mode.
ST.TRIM/TH.TRIM: Counterclockwise adjustment to increase the trim value. The maximum value is 120us.
ST.TRIM/TH.TRIM: Clockwise adjustment to decrease the trim value. The minimum value is -120us.
Note: After the throttle trim is changed, the receiver needs to be re-powered on to recognize the new
throttle neutral. Otherwise, an exception may occur during vehicle reversing.
该功能用于调整通道的动作方向。
旋钮 ST.REV/TH.REV 分别为 CH1、CH2 通道反向按键，开关上拨表示反向，下拨表示正常。
ST.TRIM 为 CH1 方向微调，可复用为 CH3 通道微调；
TH.TRIM 为 CH2 油门微调，可复用为 CH4 通道微调；
以上具体复用切换方式见 [模式切换 ]。
调节范围：-120us ~ +120us；
ST.TRIM/TH.TRIM：逆时针调节，增大微调值，最大为 120us；
ST.TRIM/TH.TRIM：顺时针调节，减少微调值，最小为 -120us。
注：CH2 油门微调调整后，接收机须重新通电以识别新的油门中位，否则可能会出现倒车异常的现象。
