The ST. D/R switch is used to adjust the servo travel amount, and can also adjust the travel amount for
CH3 as multiplexing mode.
The TH.D/R switch is used to adjust the servo travel amount for CH2(throttle), and can also adjust the
travel amount for CH4.
Refer to [Mode Switching] for multiplexing switching mode.
Adjustment range: 0-120%;
ST.D/R: Counterclockwise adjustment to increase the servo travel amount. The maximum value is 120%.
ST.D/R: Clockwise adjustment to decrease the servo amount. The minimum value is 0%.
TH.D/R: Counterclockwise adjustment to increase the servo amount. The maximum value is 120%.
TH.D/R: Clockwise adjustment to decrease the servo amount. The minimum value is 0%.
The failsafe function is used to protect the model and personnel when the receiver is out-of-control. The
failsafe for CH2 is enabled by defaut, the ESCl will enter the brake state when the receiver is out-ofcon-
trol. By default, the failsafe for CH1, CH3 and CH4 channels have not set, and can be set at the
transmitter side, and these three channels will maintain the last output in case of out-of-control.
Setup:
In the normal power-on state, set the control corresponding to the channel to be configured with failsafe
to the preset position, meanwhile, press and hold the BIND button for 3 senconds to set the output value
as the failsafe value. And if the G.LED flashes for 2 seconds, it indicates that the setting is successful.
Then the failsafe value set will output in case of out-of-control.
This function is for reusing the ST.TRIM and ST.D / R buttons for different channels
setting:
Under normal power-on condition, press the BIND button twice (within 1S) to switch between mode 1
and mode 2. By default, mode 1 is used.
Mode 1: R.LED is always on. G.LED is off. ST.TRIM is for CH1 trim. ST.D/R is for CH1 ser vo adjust-
ment . TH.TRIM is for CH2 throttle trim. TH.D/R is for CH2 throttle ser vo adjustment .
Mode 2: R.LED and G.LED are flashing alternately. ST.TRIM is for CH3 trim. ST.D/R is for CH3 ser vo
adjustment . TH.TRIM is for CH4 trim. TH.D/R is for CH4 ser vo adjustment .
16
D/R
舵量调节
Mode switching
模式切换
Failsafe
失控保护
System Functions
系统功能
ST.D/R 为 CH1 方向舵量调节，可复用为 CH3 舵量调节；
TH.D/R为 CH2 油门舵量调节，可复用为 CH4 舵量调节；
调节范围：0 ~ 120%；
ST.D/R：逆时针调节，增加舵量，最大为 120%；
ST.D/R：顺时针调节，减小舵量最小为 0%。
TH.D/R：逆时针调节，增加舵量，最大为 120%；
TH.D/R：顺时针调节，减小舵量最小为 0%。
此功能用于将 ST.TRIM 及 ST.D/R 旋钮复用于 CH3、CH4 通道（详见 [微调 ]、[舵量调节 ]。
功能设置：
正常开机状态下快速短按两下对码按键（BIND）（1 秒 内）即可循环切换模式一、二，开机默认为模式一。
模式一：R.LED 指示灯常亮，G.LED 示灯不亮，ST.TRIM 调节 CH1 微调，ST.D/R 调节 CH1 舵量；
TH.TRIM 调节 CH2 油门微调，TH.D/R 调节 CH2 油门舵量；
模式二：R.LED 指示灯和 G.LED 指示灯交替闪烁，ST.TRIM 调节 CH3 微调，ST.D/R 调节 CH3 舵量；
TH.TRIM 调节 CH4 微调，TH.D/R 调节 CH4 舵量。
