Group 01 Basic Motor Parameters
Param.
#
Parameter Name Setting Range Default Unit
Control Mode
Notes
V/F SLV PM/SLV
01-00 V/F Curve Motor 1 0–FF F -
X X *3, (Note)
01-02 Maximum Output Frequency Motor 1 4.8–599.0 50.0/60.0 Hz
*8
01-03 Maximum Output Voltage Motor 1
240V: 0.1–255.0 230
V
X X *8
480V: 0.2–510.0 460
01-04 Middle Output Frequency 2 Motor 1 0.1–599.0 0 Hz
X X (Note)
01-05 Middle Output Voltage 2 Motor 1
240V: 0.0–255.0
0 V
X X *8, (Note)
480V: 0.0–510.0
01-06 Middle Output Frequency 1 Motor 1 0.1–599.0 3 Hz
X X (Note)
01-07 Middle Output Voltage 1 Motor 1
240V: 0.0–255.0
KVA V
X X *8, (Note)
480V: 0.0–510.0
01-08 Minimum Output Frequency Motor 1 0.1–599.0
V/F: KVA
Hz
(Note)SLV: 0.6
PMSLV: 10
01-09 Minimum Output Voltage Motor 1
240V: 0.0–255.0
KVA V
X X *8
480V: 0.0–510.0
01-10 Torque Compensation Gain 0–10.0 0.5 -
X X *1
01-11 Torque Compensation Mode
0: Mode 0 (Normal)
0 -
X X
1: Mode 1 (High Speed)
01-12 Nameplate Frequency of Motor 1 4.8–599.0 50.0/60.0 Hz
X *8
01-13
Base (Nameplate) Output Voltage
Motor 1
240V: 0.0–255.0 230
V
X X *8
480V: 0.0–510.0 460
01-14 Input Voltage Setting
240V: 55.0–255.0 230
V
*8
480V: 10.0–510.0 460
01-15 Torque Compensation Time 0–10000 200 ms
X X
01-16 Maximum Output Frequency Motor 2 4.8–599.0 50.0/60.0 Hz
X X *8
01-17 Maximum Output Voltage Motor 2
240V: 0.1–255.0 230
V
X X *8
480V: 0.2–510.0 460
01-18 Middle Output Frequency 2 Motor 2 0.0–599.0 0 Hz
X X
01-19 Middle Output Voltage 2 Motor 2
240V: 0.0–255.0
0 V
X X
480V: 0.0–510.0
01-20 Middle Output Frequency 1 Motor 2 0.0–599.0 3 Hz
X X
01-21 Middle Output Voltage 1 Motor 2
240V: 0.0–255.0
KVA V
X X
480V: 0.0–510.0
01-22 Minimum Output Frequency Motor 2 0.0–599.0 1.5 Hz
X X
01-23 Minimum Output Voltage Motor 2
240V: 0.0–255.0
KVA V
X X
480V: 0.0–510.0
01-24 Nameplate Frequency Motor 2 4.8–599.0 50.0/60.0 Hz
X X *8
01-25
Base (Nameplate) Output Voltage
Motor 2
240V: 0.0–255.0 230
V
X X *8
480V: 0.0–510.0 460
01-26 V/F Curve Motor 2 0–FF F -
X X *3
01-00:
When editing using the LED keypad, display shows H00XX indicating the value is to be input as a hexadecimal.
01-04 to 01-07 and 01-18 to 01-21:
Values are only editable when 01-00=F or FF
*1: Parameter can be changed while running.
*3: Parameter will not reset to default during a factory reset (initialization).
*8: Parameter value / default setting is dependent on drive size / model
